Characterization of single-mode vertical cavity surface-emitting lasers
National Conference on Undergraduate Research
A high-quality single-mode beam is desirable for the efficient use of lasers as light sources for optical data communications and interconnects, however there is little data which characterizes operating ranges and near-field beam qualities of Vertical Cavity Surface Emitting Lasers (VCSELs), which has resulted in a lack of analysis of these devices. Measures of beam quality include beam-quality factor (M2), Side-Mode-Suppression-Ratio (SMSR) and RMS linewidth. M2 is a measurement of how closely the beam is to an ideal Gaussian. SMSR is the difference, in dB, between the amplitude of the primary peak and the amplitude of the next highest peak of the output spectrum, with single-mode operation defined by a SMSR > 30 dB. RMS linewidth is a second moment calculation involving the power spectral density, where smaller RMS linewidth indicates higher beam quality. Utilizing a novel vertical M2 setup in which on-wafer VCSEL M2 can be measured, a study was conducted on the relation between M2, SMSR and RMS linewidth, for various oxide-confined VCSELs of varying aperture sizes and Photonic Crystal (PhC) VCSELs of varying aperture sizes and photonic crystal configurations. First, the operating range of the VCSEL was determined utilizing a Semiconductor Parameter Analyzer to obtain the LIV characteristics. Along with this measurement, spectral data was collected using an Optical Spectrum Analyzer at several key operating points, which allowed the RMS linewidths and SMSRs of the devices to be calculated at these points. The novel beam-profiler setup was used to measure the device’s M2. Initial results show a strong correlation between the measures of beam quality, with increasing SMSR, corresponding to M2 values closer to 1, and single-mode operation characterized by a M2 of less than 1.5. A strong correlation between RMS linewidth and M2 was also seen, with increasing RMS linewidths corresponding to an increase in M2.
Conference presentations, papers, posters
VCSEL, Single-mode, Beam quality, Photonic crystal
CDT Jonathan Dencker, CDT Peter R. Zeidler, CDT David Chacko, William North, Janice Blane, Kirk A. Ingold, Brian Souhan, and James J. Raftery Jr., “Characterization of single-mode vertical cavity surface-emitting lasers,” Proceedings of the 2016 National Conference on Undergraduate Research (NCUR), Asheville, NC, (April 2016).
